Kinney KT 300D - NEW

Starting at $29,895
In stock
Only %1 left
SKU
NEW_KT300D
Weight 1525 lbs
Motor Power 15 hp
Pumping Speed 300 cfm
Ultimate Pressure 1.0 x 10-2 Torr

Kinney KT 300D Rotary Piston Vacuum Pump - NEW

The KT-Series pump has an oil circulating pump to provide adequate lubrication at all pressures including atmosphere. The vacuum pump has three cams and pistons pumping in parallel, driven by a common shaft. The cams are positioned on the shaft so as to dynamically balance moving parts to eliminate vibration. We also offer repair service backed by a one year warranty. Mist filters are sold separately.

Motor Power (hp): 15

Ultimate Pressure (Torr): 0.010

Pumping Speed (cfm): 300

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Free air displacement 300 cfm 510 m3/h
Motor power 15 hp
Rotation speed 870 rpm
Oil capacity (total/refill) 10/8.5 gal 38/32 liters
Cooling water at 60°F (16°C) 1.5 gpm 6 l/min
Cooling water inlet connection     3/8" NPT
Suction connection 4" 150 lb ANSI flanged
Discharge connection 3" 150 lb ANSI flanged
Height w/o oil mist eliminator 51 in
Floor space required 27 x 34 in
Weight 1,525 lbs
Ultimate pressure 1.0 × 10-2 Torr
Noise level (typical at .1 torr) 72 dBA

Specs

Type Label Description Download
Kinney KT Series - NEW OPERATOR’S MANUAL Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Kinney KT 300D Rotary Piston Vacuum Pump - NEW

KT300D-M4A0 TEFC 3/60/230-460
KT300D-M4E0 TEFC 3/60/575
KT300D-M4D0 TEFC 3/50/220-380-440
KT300D-M7H0 Class 1 Div 1 Group C&D 3/60/230-460
KT300D-M7M0 Class 1 Div 1 Group C&D 3/60/575
